Planet GS-4210-16T2S User Manual

User’s Manual of GS-4210-16T2S_24T2S_16P2S_24P2S_48T4S
314
The page includes the following fields:
Object Description
• ACL Name
Select ACL name for this drop down list.
• Sequence
Set the ACL sequence.
• Action
Indicates the forwarding action of the ACE.
 Permit: Frames matching the ACE may be forwarded and learned.
 Deny: Frames matching the ACE are dropped.
• Protocol
Specify the protocol filter for this ACE.
 Any(IP): No protocol filter is specified.
 Select from list: If you want to filter a specific protocol with this ACE, choose
this value and select protocol for this drop down list.
 Protocol ID to match: I If you want to filter a specific protocol with this ACE,
choose this value and set currect protocol ID.
• Source IP Address
Specify the Source IP address filter for this ACE.
 Any: No source IP address filter is specified.
 User Defined: If you want to filter a specific source IP address with this ACE,
choose this value. A field for entering a source IP address value appears.
• Source IP Address
Value
When "User Defined" is selected for the source IP address filter, you can enter a
specific source IP address. The legal format is "xxx.xxx.xxx.xxx". A frame that
hits this ACE matches this source IP address value.
• Source IP Mask
When "User Defined" is selected for the source IP filter, you can enter a specific
SIP mask in dotted decimal notation.
• Destination IP Address
Specify the Destination IP address filter for this ACE.
 Any: No destination IP address filter is specified.
 User Defined: If you want to filter a specific destination IP address with this
ACE, choose this value. A field for entering a source IP address value
appears.
• Destination IP Address
Value
When "User Defined" is selected for the destination IP address filter, you can
enter a specific destination IP address. The legal format is "xxx.xxx.xxx.xxx". A
frame that hits this ACE matches this destination IP address value.
• Destination IP Mask
When "User Defined" is selected for the destination IP filter, you can enter a
specific DIP mask in dotted decimal notation.
• Source Port
Specify the source port for this ACE.
 Any: No specifc source port is specified (source port status is "don't-care").
 Single: If you want to filter a specific source port with this ACE, you can
enter a specific source port value. A field for entering a source port value
appears. The allowed range is 0 to 65535. A frame that hits this ACE
matches this source port value.

Planet GS-4210-16T2S Specifications

General

Switch type	Managed
Switch layer	L2/L4
Quality of Service (QoS) support	Yes
Console port	RJ-45
SFP module slots quantity	2
Installed SFP modules quantity	0
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	16
10G support	No
Number of VLANs	4094
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-TX, 1000BASE-T
Authentication	Port-based authentication
Security algorithms	802.1x RADIUS, HTTPS, SSH, SSL/TLS
Stackable	-
Form factor	1U
Certification	FCC, CE
Product color	Blue
Housing material	Metal
Throughput	26.7 Mpps
Jumbo frames	9216
MAC address table	8000 entries
Supported network protocols	IPv4 / IPv6
Input current	0.8 A
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	10.4 W
Heat dissipation	35 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Fiber ethernet cabling technology	1000BASE-X
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	207 mm
Width	445 mm
Height	45 mm
Weight	2000 g
