User’s Manual of GS-4210-16T2S_24T2S_16P2S_24P2S_48T4S
321
matches this source port value.
 Range: If you want to filter a specific source port range filter with this ACE,
you can enter a specific source port range value. A field for entering a source
port value appears. The allowed range is 0 to 65535. A frame that hits this
ACE matches this source port value.
• Destination Port
Specify the destination port for this ACE.
 Any: No specifc destination port is specified (destination port status is
"don't-care").
 Single: If you want to filter a specific destination port with this ACE, you can
enter a specific destination port value. A field for entering a destination port
value appears. The allowed range is 0 to 65535. A frame that hits this ACE
matches this destination port value.
 Range: If you want to filter a specific destination port range filter with this
ACE, you can enter a specific destination port range value. A field for
entering a destination port value appears.
• TCP Flags
URG Specify the TCP "Urgent Pointer field significant" (URG) value for this
ACE.
 Set: TCP frames where the URG field is set must be able to match
this entry.
 Unset: TCP frames where the URG field is set must not be able to
match this entry.
 Don’t Care: Any value is allowed ("don't-care").
ACK Specify the TCP "Acknowledgment field significant" (ACK) value for this
ACE.
 Set: TCP frames where the ACK field is set must be able to match
this entry.
 Unset: TCP frames where the ACK field is set must not be able to
match this entry.
 Don’t Care: Any value is allowed ("don't-care").
PSH Specify the TCP "Push Function" (PSH) value for this ACE.
 Set: TCP frames where the PSH field is set must be able to match
this entry.
 Unset: TCP frames where the PSH field is set must not be able to
match this entry.
 Don’t Care: Any value is allowed ("don't-care").
RST Specify the TCP "Reset the connection" (RST) value for this ACE.
 Set: TCP frames where the RST field is set must be able to match
this entry.
 Unset: TCP frames where the RST field is set must not be able to
match this entry.

Planet GS-4210-16T2S Specifications

General

Switch type	Managed
Switch layer	L2/L4
Quality of Service (QoS) support	Yes
Console port	RJ-45
SFP module slots quantity	2
Installed SFP modules quantity	0
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	16
10G support	No
Number of VLANs	4094
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-TX, 1000BASE-T
Authentication	Port-based authentication
Security algorithms	802.1x RADIUS, HTTPS, SSH, SSL/TLS
Stackable	-
Form factor	1U
Certification	FCC, CE
Product color	Blue
Housing material	Metal
Throughput	26.7 Mpps
Jumbo frames	9216
MAC address table	8000 entries
Supported network protocols	IPv4 / IPv6
Input current	0.8 A
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	10.4 W
Heat dissipation	35 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Fiber ethernet cabling technology	1000BASE-X
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	207 mm
Width	445 mm
Height	45 mm
Weight	2000 g
