User’s Manual of GS-4210-16T2S_24T2S_16P2S_24P2S_48T4S
368
The page includes the following fields:
Object Description
• Maximum PoE Budget
(watts)
Allow assign PoE Budget to the PoE Managed Switch.
The range is 0-220 watts and default is 220 watts. (GS-4210-16P2S)
The range is 0-300 watts and default is 300 watts. (GS-4210-24P2S)
• Systsem Operation
Status
Display current system operation status.
• Power Allocation
Dislpay current power allocation value in watts.
• PoE Temperature
• Port 1 -8
Display the current PoE chipset temperature of port 1-8.
• PoE Temperature
• Port 9 -16
Display the current PoE chipset temperature of port 9-16.
• PoE Temperature
• Port 17 -24
Display the current PoE chipset temperature of port 17-24. (GS-4210-24P2S)
