Planet GS-4210-16T2S User Manual

User’s Manual of GS-4210-16T2S_24T2S_16P2S_24P2S_48T4S
382
• Sample Type
The method of sampling the selected variable and calculating the value to be
compared against the thresholds, possible sample types are:
 Absolute: Get the sample directly (default).
 Delta: Calculate the difference between samples.
• Rising Threshold
Rising threshold value (0–2147483647).
• Falling Threshold
Falling threshold value (0–2147483647).
• Rising Event
Event to fire when the rising threshold is crossed.
• Falling Event
Event to fire when the falling threshold is crossed.
• Owner
Specify an owner for the alarm.
Button
: Click to apply changes.
Figure 4-15-6: RMON Alarm Status Page Screenshot
The Page includes the following fields:
Object Description
• Index
Indicates the index of Alarm control entry.
• Sample Port
Display the current sample port.
• Sample Variable
Display the current sample variable.
• Sample Interval
Display the current interval.
• Sample Type
Display the current sample type.
• Rising Threshold
Display the current rising threshold.
• Falling Threshold
Display the current falling threshold.
• Rising Event
Display the current rising event.
• Falling Event
Display the current falling event.
• Owner
Display the current owner.
• Action
Click
to delete RMON alarm entry.

Planet GS-4210-16T2S Specifications

General

Switch type	Managed
Switch layer	L2/L4
Quality of Service (QoS) support	Yes
Console port	RJ-45
SFP module slots quantity	2
Installed SFP modules quantity	0
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	16
10G support	No
Number of VLANs	4094
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-TX, 1000BASE-T
Authentication	Port-based authentication
Security algorithms	802.1x RADIUS, HTTPS, SSH, SSL/TLS
Stackable	-
Form factor	1U
Certification	FCC, CE
Product color	Blue
Housing material	Metal
Throughput	26.7 Mpps
Jumbo frames	9216
MAC address table	8000 entries
Supported network protocols	IPv4 / IPv6
Input current	0.8 A
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	10.4 W
Heat dissipation	35 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Fiber ethernet cabling technology	1000BASE-X
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	207 mm
Width	445 mm
Height	45 mm
Weight	2000 g
