User’s Manual of GS-4210-16T2S_24T2S_16P2S_24P2S_48T4S
Button
: Click to apply changes.
Figure 4-3-10: Mirroring Status Page Screenshot
The page includes the following fields:
Object Description
• Session ID
Display the session ID.
• Destination Port
This is the mirroring port entry.
• Ingress State
Display the ingress state.
• Source TX Port
Display the current TX ports.
• Source RX Port
Display the current RX ports.
