3
9850067 R01 - 2020-2021 GENERAL / GENERAL XP Service Manual
© Copyright Polaris Inc.
3.75
7. Install the fasteners holding the air box assembly to
the rear upper close-off panel and the frame of the
vehicle. Torque the fasteners to specification.
TORQUE
Air Box Fasteners:
3.5 lb-ft (4.7 Nm)
8. Install the clamp holding the engine crankcase
breather hose to the engine. Refer to “Engine
Crankcase Breather Hose Inspection” page 2.29
procedure.
9. Remove clean cloth in Electronic Throttle Control
(ETC) inlet preventing anything from entering engine.
Install the clamp holding the engine intake hose to the
ETC. Torque to specification.
TORQUE
Engine Intake Hose Clamp:
49 lb-in (5.5 Nm)
10.Lower the cargo box and secure in position.
ENGINE / COOLING SYSTEM
