9850067 R01 - 2020-2021 GENERAL / GENERAL XP Service Manual
© Copyright Polaris Inc.
1.39
r
Does the engine
crank?
Yes
• Check Oil level. If not full, fill to correct level.
• Check Fuel Level. (Check tank using flash light - gauge may not be accurate
- add fuel if needed)
• Check Coolant level. If not full, fill to correct level.
Continue to step
t
No
• Check Oil level. If oil is low concern may be caused by lack of oil or oil
pressure. Suspect internal engine issue. Refer to Chapter 3 Engine / Cooling
System.
• Check for battery power. Voltage should be ~ 12.6 V.
• Load test battery. If battery fails the load test, charge / replace battery as
needed. Retest for concern before proceeding.
• Check Ignition Switch and connections. Concern may be caused by faulty
Ignition Switch.
• Refer to No Crank No Start or Slow Crank page 1.43 for further diagnostic
procedures
t
Does the engine
stay running?
Yes
• Continue to step
y
No
• Check air filter for blockage.
• Check for spark. Refer toEngine Cranks but does Not Start page 1.41 for
quick check.
• Check fuel supply using fuel pressure gauge. Is fuel pressure within
specification?
• Check exhaust for blockage.
• After checking for air supply and fuel pressure, perform leakdown test.
• Refer to Engine Cranks but does Not Start page 1.41 for more information.
GENERAL INFORMATION
1
To Next Page
