1.40
9850067 R01 - 2020-2021 GENERAL / GENERAL XP Service Manual
© Copyright Polaris Inc.
y
Will the vehicle
move under its own
power?
Yes
• Continue to step
u
No
• Remove PVT cover if necessary and check belt for damage or unusual wear.
Refer to Belt Inspection for more information.
• If no damage is found, using the aid of an assistant slowly rev engine
observing clutch engagement. If no engagement is seen refer to PVT System
Troubleshooting.
• Using the aid of an assistant verify the propshaft is turning, while the clutch is
engaged. If the driveshaft is turning refer to Differential Diagnosis /
Disassembly in the applicable service manual.
• If the driveshaft is not moving, concern may be within transmission. Refer to
the necessary section in the applicable service manual.
u
Test drive vehicle
for concern.
• If the concern is related to the PVT system, Transmission, or Final Drive,
refer to the applicable section in the service manual.
• If the concern is electrical systems related, refer to Electrical
Troubleshooting.
• If the concern is overheating or related to the cooling system, first refer to
Over Heating page 1.44 , then Cooling Troubleshooting page 1.48.
• If the concern is driveability related (lack of power, misfire, etc.), refer to Fuel
System Troubleshooting page 1.71, or Cylinder Misfire Detection page 1.69.
These concerns may also be caused by a mechanical failure.
• If the concern can not be diagnosed or repaired using normal diagnostic
means, please contact Polaris Technical Service Team.
GENERAL INFORMATION
