9.72
9850067 R01 - 2020-2021 GENERAL / GENERAL XP Service Manual
© Copyright Polaris Inc.
4. Install wiper seal in body cap (if equipped). Apply thin
layer of Slick Honey® to seal.
5. Install body cap.
NOTICE
There are two different sides on the U-Cup seal. When
seal is installed, energizing side should be facing
internal bearing.
6. Install U-Cup seal.
7. Install back-up washer.
8. Apply thin layer of shock oil to washer.
9. Install bearing assembly using the appropriate bullet
tool.
STEERING / SUSPENSION
