10
9850067 R01 - 2020-2021 GENERAL / GENERAL XP Service Manual
© Copyright Polaris Inc.
10.29
REAR BRAKE LINE FROM JUNCTION
BLOCK TO CALIPERS ROUTING
q
RH Rear Brake Caliper
e
LH Rear Brake Caliper
w
Brake Line Retention Points
r
Junction Block
BRAKE SYSTEM
