9850067 R01 - 2020-2021 GENERAL / GENERAL XP Service Manual
© Copyright Polaris Inc.
12.45
FUSE / RELAY PIN
WIRE
COLOR
FROM COMPONENT TO COMPONENT FUNCTION
Drive 10A Fuse
28 RD/DG RELAY/FUSE BLOCK
SPLICE,CHASSIS
CHASSIS RELAY, DRIVE
INPUT
32 RD/DG
SPLICE,DRIVE
RELAY/FUSE BLOCK
SWITCHED B+, DRIVE
FUSE OUT
Key 10A Fuse
43 RD RELAY/FUSE BLOCK START SOLENOID B+
UNSWITCHED B+, KEY
FUSE IN
47 RD/WH RELAY/FUSE BLOCK KEY SWITCH KEY FUSE OUT
CIRCUIT BREAKER DETAILS
FUSE / RELAY PIN
WIRE
COLOR
FROM COMPONENT TO COMPONENT FUNCTION
Fan 25A Circuit
Breaker
44 RD RELAY/FUSE BLOCK START SOLENOID B+
FAN B+, FUSE IN
48 OG/BK RELAY/FUSE BLOCK RELAY/FUSE BLOCK
FAN B+, FUSED RELAY IN
CHASSIS / BODY ELECTRICAL
