12.44
9850067 R01 - 2020-2021 GENERAL / GENERAL XP Service Manual
© Copyright Polaris Inc.
FUSE / RELAY PIN
WIRE
COLOR
FROM COMPONENT TO COMPONENT FUNCTION
37 RD/DG RELAY/FUSE BLOCK
SPLICE,CHASSIS
CHASSIS RELAY OUT
38 GY
ECM,CODE 4
RELAY/FUSE BLOCK CHASSIS RELAY COIL LO
Info Relay
3 OG/BK
SPLICE,KEY SW ACC
RELAY/FUSE BLOCK
KEY ACC,INFO REL COIL
4 RD/WH RELAY/FUSE BLOCK INFOTAINMENT INFO B+ SW
7 RD
SPLICE,INFO
RELAY/FUSE BLOCK UNSW INFO B+ RELAY IN
8 BN RELAY/FUSE BLOCK
SPLICE, COIL GND
INFO REL COIL GND
EFI Relay
19 RD/WH RELAY/FUSE BLOCK
SPLICE,B+ UNSWITCHED
FUSED #1
UNSWITCHED FUSED B+,
EFI RELAY COIL HI
20 RD RELAY/FUSE BLOCK RELAY/FUSE BLOCK
UNSWITCHED FUSED B+,
EFI RELAY IN
23 RD/DB RELAY/FUSE BLOCK
SPLICE,EFI B+ 2 EFI B+, EFI RELAY OUT
24 DG/YE
ECM,CODE 4
RELAY/FUSE BLOCK EFI RELAY COIL LO
Term Relay
35 OG/BK
SPLICE,KEY SW ACC
RELAY/FUSE BLOCK
KEY ACC,ACC REL COIL
36 OG/WH RELAY/FUSE BLOCK
SPLICE,TERM
TERM REL OUT
39 RD RELAY/FUSE BLOCK RELAY/FUSE BLOCK TERM FUSE OUT
40 BN RELAY/FUSE BLOCK
SPLICE, COIL GND
GROUND, TERM RELAY
COIL
FUSE DETAILS
FUSE / RELAY PIN
WIRE
COLOR
FROM COMPONENT TO COMPONENT FUNCTION
EFI 10A Fuse
17 RD
SPLICE, EFI
RELAY/FUSE BLOCK
EFI B+, FUSE IN
21 RD RELAY/FUSE BLOCK RELAY/FUSE BLOCK
UNSWITCHED FUSED B+,
EFI RELAY IN
Lights 15A Fuse
18 RD/DG
SPLICE,CHASSIS
RELAY/FUSE BLOCK
CHASSIS RELAY OUT,
LIGHTS INPUT
22 RD/YE RELAY/FUSE BLOCK
SPLICE,LIGHTS B+
LIGHTS B+, LIGHTS FUSE
OUT
Term 10A Fuse
41 RD RELAY/FUSE BLOCK
SPLICE, ACCY
UNSWITCHED ACC B+,
TERM FUSE IN
45 RD RELAY/FUSE BLOCK RELAY/FUSE BLOCK TERM FUSE OUT
Accessory 10A
Fuse
42 RD RELAY/FUSE BLOCK
SPLICE, ACCY
UNSWITCHED ACC B+,
ACCY FUSE IN
46 RD RELAY/FUSE BLOCK
12V RECEPTACLE HI
(DASH)
12V ACCY,FUSE OUT
Info 25A Fuse
11 RD
SPLICE, ACCY
RELAY/FUSE BLOCK
UNSWITCHED ACC B+,
INFO FUSE IN
15 RD RELAY/FUSE BLOCK
SPLICE,INFO
B+ INFO FUSED, INFO
RELAY IN
EPS 30A Fuse
12 RD RELAY/FUSE BLOCK START SOLENOID B+
EPS B+, FUSE IN
16 OG EPS POWER RELAY/FUSE BLOCK EPS FUSE POWER OUT
UNSW 10A Fuse
27 RD
SPLICE, EFI
RELAY/FUSE BLOCK
UNSW B+, FUSE IN
31 RD/WH RELAY/FUSE BLOCK
SPLICE,B+ UNSWITCHED
FUSED #1
UNSWITCHED FUSED B+,
UNSW FUSE OUT
CHASSIS / BODY ELECTRICAL
