9850067 R01 - 2020-2021 GENERAL / GENERAL XP Service Manual
© Copyright Polaris Inc.
12.53
FUSE / RELAY PIN
WIRE
COLOR
FROM COMPONENT TO COMPONENT FUNCTION
16 OG/BK RELAY/FUSE BLOCK RELAY/FUSE BLOCK
FAN B+, FUSED RELAY IN
21 OG/BK RELAY/FUSE BLOCK FAN
FAN B+, RELAY OUT
22 OG/BK
ECM,CODE 4
RELAY/FUSE BLOCK FAN COIL LOW
Headlight Relay
39 YE/DG KEY SWITCH RELAY/FUSE BLOCK
KEY OUT,HEADLIGHT
RELAY ENABLE
40 RD/YE
SPLICE, HEADLIGHT
RELAY FUSE LINK
RELAY/FUSE BLOCK HEADLIGHT RELAY IN
45 RD/YE RELAY/FUSE BLOCK
SPLICE, LIGHTS
HEADLIGHT/FOG RELAY
OUT
46 BN RELAY/FUSE BLOCK
SPLICE, GND FUSE
CENTER
GROUND
Info Relay
5 OG RELAY/FUSE BLOCK
SPLICE,R/S B+2
KEY SW B+, INFO REL
COIL POWER
6 RD/WH RELAY/FUSE BLOCK
INFOTAINMENT
CONNECTOR
INFO REL OUT
11 RD
SPLICE, INFOTAINMENT
RELAY/FUSE BLOCK
FUSED B+, INFO RELAY
IN
12 BN RELAY/FUSE BLOCK
SPLICE, GND FUSE
CENTER
GROUND, SPLICE COIL
EFI Relay
29 RD/WH RELAY/FUSE BLOCK
SPLICE,B+ UNSWITCHED
FUSED #1
UNSWITCHED FUSED B+,
EFI RELAY COIL HI
30 RD RELAY/FUSE BLOCK RELAY/FUSE BLOCK
UNSWITCHED FUSED B+,
EFI RELAY IN
35 RD/DB RELAY/FUSE BLOCK
SPLICE,EFI B+ EFI B+, EFI RELAY OUT
36 DG/YE
ECM,CODE 4
RELAY/FUSE BLOCK EFI RELAY COIL LO
FUSE DETAILS
FUSE / RELAY PIN
WIRE
COLOR
FROM COMPONENT TO COMPONENT FUNCTION
Headlight 15A Fuse
13 RD/YE
SPLICE, LIGHTS
RELAY/FUSE BLOCK HEADLIGHT FUSE IN
19 RD/YE RELAY/FUSE BLOCK
TURN/LIGHT/HORN
SWITCH
HEADLIGHT FUSE OUT
12V Rec 10A Fuse
14 RD/DG
SPLICE,CHASSIS
RELAY/FUSE BLOCK 12V ACCESSORY FUSE IN
20 OG/WH RELAY/FUSE BLOCK
12V RECEPTACLE #1 (HI)
3/16"
12V ACCESSORY FUSE
OUT
Info 25A Fuse
37 RD START SOLENOID B+ 1 RELAY/FUSE BLOCK UNFUSED B+ INFO
43 RD RELAY/FUSE BLOCK
SPLICE, INFOTAINMENT
FUSED B+ INFO
ABS IGN 2A Fuse
3 OG
SPLICE,R/S B+2
RELAY/FUSE BLOCK
KEY SWITCH B+, ABS
8 BN RELAY/FUSE BLOCK
ECM,CODE 13
GROUND, START RELAY
COIL
ABS Sensors 5A
Fuse
4 RD
SPLICE, ABS
RELAY/FUSE BLOCK
ABS SENSORS, FUSE IN
9 OG/WH RELAY/FUSE BLOCK ABS CONTROLLER
KEY SWITCH B+, ABS
FUSED
ABS Valves 20A
Fuse
28 RD
SPLICE, ABS
RELAY/FUSE BLOCK
ABS VALVES, FUSE IN
CHASSIS / BODY ELECTRICAL
