FUSE / RELAY PIN
WIRE
COLOR
FROM COMPONENT TO COMPONENT FUNCTION
34 RD/YE RELAY/FUSE BLOCK ABS CONTROLLER
ABS VALVES, FUSE OUT
Brake 10A Fuse
51 OG RELAY/FUSE BLOCK
SPLICE,BRAKE
VEHICLE BRAKE SIGNAL
FUSE IN
57 OG BOX HARNESS RELAY/FUSE BLOCK
VEHICLE BRAKE FUSE
OUT
Accessory 10A
Fuse
52 RD/DG RELAY/FUSE BLOCK
SPLICE,CHASSIS
ACCESSOY FUSE IN
58 OG/WH RELAY/FUSE BLOCK
SPLICE, ACCESSORY
ACCESSOY FUSE OUT
Trailer Brake 10A
Fuse
63 OG
SPLICE,BRAKE
RELAY/FUSE BLOCK
TRAILER BRAKE SIGNAL
FUSE IN
69 OG RELAY/FUSE BLOCK TRAILER JUMPER
BRAKE SIGNAL FUSE
OUT
Flasher 10A Fuse
64 RD
SPLICE, FLASHER
MODULE FUSE LINK
RELAY/FUSE BLOCK
FLASHER MODULE FUSE
IN
70 RD/WH FLASHER MODULE RELAY/FUSE BLOCK
FLASHER MODULE FUSE
OUT
Key 10A Fuse
17 RD RELAY/FUSE BLOCK
SPLICE,KEY B+ FUSIBLE
LINK
KEY B+ UNFUSED
23 RD/WH KEY SWITCH RELAY/FUSE BLOCK KEY FUSE OUT
EPS 30A Fuse
18 RD RELAY/FUSE BLOCK START SOLENOID B+ 1 UNFUSED B+ EPS
24 RD EPS POWER RELAY/FUSE BLOCK EPS FUSE POWER OUT
EFI 15A Fuse
41 RD
SPLICE, EFI
RELAY/FUSE BLOCK
EFI B+, FUSE IN
47 RD RELAY/FUSE BLOCK RELAY/FUSE BLOCK
UNSWITCHED FUSED B+,
EFI RELAY IN
Lights 20A Fuse
42 RD/DG
SPLICE,CHASSIS
RELAY/FUSE BLOCK
CHASSIS RELAY OUT,
LIGHTS INPUT
48 RD/YE RELAY/FUSE BLOCK
SPLICE,FUSED LIGHTS B
+
LIGHTS B+,LIGHTS FUSE
OUT
UNSW 10A Fuse
53 RD
SPLICE, EFI
RELAY/FUSE BLOCK
UNSWCH B+, FUSE IN
59 RD/WH RELAY/FUSE BLOCK
SPLICE,B+ UNSWITCHED
FUSED #1
UNSWITCHED FUSED B+,
KEY FUSE OUT
Drive 10A Fuse
54 RD/DG RELAY/FUSE BLOCK
SPLICE,CHASSIS
CHASSIS RELAY, DRIVE
INPUT
60 RD/DG RELAY/FUSE BLOCK
SPLICE, DRIVE
SWITCHED B+ DRIVE
FUSE OUT
Fog 5A Fuse
65 RD/YE
SPLICE, LIGHTS
RELAY/FUSE BLOCK FOG LIGHT B+
71 RD RELAY/FUSE BLOCK FOG LIGHT SW FOG LIGHT FUSE OUT
CIRCUIT BREAKER DETAILS
FUSE / RELAY PIN
WIRE
COLOR
FROM COMPONENT TO COMPONENT FUNCTION
Fan 25A Circuit
Breaker
66 RD RELAY/FUSE BLOCK
SPLICE,FAN B+ FUSIBLE
LINK
FAN B+, FUSE IN
72 OG/BK RELAY/FUSE BLOCK RELAY/FUSE BLOCK
FAN B+, FUSED RELAY IN
