Remote control commands
R&S
®
NRPxxS(N)
125User Manual 1177.5079.02 ─ 15
CALibration:DATA.......................................................................................................... 125
CALibration:DATA:LENGth?............................................................................................125
CALibration:USER:DATA................................................................................................ 125
CALibration:USER:DATA:LENGth?.................................................................................. 125
CALibration<Channel>:ZERO:AUTO................................................................................126
CALibration:DATA <caldata>
Writes a binary calibration data set in the memory of the power sensor.
Parameters:
<caldata> <block_data>
CALibration:DATA:LENGth?
Queries the length in bytes of the calibration data set currently stored in the flash mem-
ory. Programs that read out the calibration data set can use this information to deter-
mine the capacity of the buffer memory required.
Example:
CAL:DATA:LENG?
Query
57392
Response
Usage: Query only
CALibration:USER:DATA <caldata>
Transfers the user calibration data set, which mainly contains S-parameter sets for
user-specific devices. The query returns the data as it was downloaded to the power
sensor before.
After downloading of a new user calibration data set to the power sensor, the current
S-parameter correction settings become invalid. Safe operation of the power sensor is
only possible if the SELect and STATe commands are repeated after download. See
also:
●
[SENSe<Sensor>:]CORRection:SPDevice:STATe
●
[SENSe<Sensor>:]CORRection:SPDevice:SELect
Parameters:
<caldata> <block_data>
CALibration:USER:DATA:LENGth?
Queries the length of the user calibration data block.
Usage:
Query only
Calibrating, zeroing
