CALCulate<Chn>:FILTer[:GATE]:TIME:WINDow <TimeGate>
Selects the time gate to be applied to the time domain transform.
Suffix:
<Chn>
.
Channel number used to identify the active trace
Parameters:
<TimeGate> RECT | HAMMing | HANNing | BOHMan | DCHebyshev
RECT - steepest edges (rectangle)
HANN - normal gate (Hann)
HAMMing - steep edges (Hamming)
BOHMan - minimum flatness (Bohman)
DCHebyshev - arbitrary gate shape (Dolph-Chebychev)
*RST: HANN
Example: See CALCulate<Chn>:FILTer[:GATE]:TIME:DCHebyshev
Manual operation: See "Shape" on page 409
7.3.1.8
CALCulate:FMODel...
The CALCulate:FMODel... commands are related to "fixture modeling" tools (see
Chapter 4.6.2.9, "Fixture modeling and deembedding", on page 215).
In the current implementation the firmware assumes that balanced fixture modeling
and dembedding is required, whenever a balanced port is configured.
A mixture of single-ended and balanced fixture modeling is not supported.
CALCulate:FMODel:DELT...
Commands for Delta-L PCB characterization (see Chapter 4.7.17, "Delta-L 4.0 PCB
characterization", on page 271).
CALCulate:FMODel:DELT<Ph_pt>:DIRectory................................................................... 929
CALCulate:FMODel:DELT<Ph_pt>:DIRectory:DEFault.......................................................929
CALCulate:FMODel:DELT<Ph_pt>:FREQuencies:CURRent?.............................................930
CALCulate:FMODel:DELT<Ph_pt>:FREQuencies:CURRent:COUNt?................................. 930
CALCulate:FMODel:DELT<Ph_pt>:FREQuencies:DEFault?............................................... 930
CALCulate:FMODel:DELT<Ph_pt>:FREQuencies:DEFault:COUNt?....................................930
CALCulate:FMODel:DELT<Ph_pt>:FREQuencies:USEDefault............................................931
CALCulate:FMODel:DELT<Ph_pt>:FREQuencies:USER?..................................................931
CALCulate:FMODel:DELT<Ph_pt>:FREQuencies:USER:COUNt?...................................... 932
CALCulate:FMODel:DELT<Ph_pt>:FREQuencies:USER:ADD............................................932
CALCulate:FMODel:DELT<Ph_pt>:FREQuencies:USER:DELete........................................932
CALCulate:FMODel:DELT<Ph_pt>:FREQuencies:USER:DELete:ALL................................. 932
CALCulate:FMODel:DELT<Ph_pt>:M1L:CACHe:CLEar:ALL...............................................933
CALCulate:FMODel:DELT<Ph_pt>:M1L:CACHe:CLEar:SELected...................................... 933
CALCulate:FMODel:DELT<Ph_pt>:M1L:FILename............................................................933
CALCulate:FMODel:DELT<Ph_pt>:M2L:FILename............................................................933
CALCulate:FMODel:DELT<Ph_pt>:M3L:FILename............................................................933
