Installation
Vacuum spray degassing20.05.2019
English 13
Room temperature > 0 - 35 °C.
Drain for drain water.
Filling connection.
DN 15 according to DIN EN 1717.
Electric connection.
230 V~, 50 Hz, 16 A with upstream RCD (tripping current: 0.03 A).
6.3 Execution
CAUTION
Risk of injury due to tipping over of the device
Risk of bruising or crushing caused by tipping over of the device.
Ensure sufficient stability of the device.
Weigh down the bearing surface of the device's transport unit with suitable means.
Note!
The screw connections at the device may loosen when the device is moved to another location.
Before using the device check the screw connections for proper seating and sealing
Note!
Avoid leaks at the connections.
When connecting the device to the plant system, ensure that the connections for degassing and make-up are
not twisted.
Proceed as follows:
Connect the device on the return side of the facility system.
Ensure that the device is operated within the permissible pressure and temperature ranges.
In the case of a facility system with return flow admixture or a hydraulic switching point, connect the device upstream of the
switching point.
In doing so, you guarantee water degassing in the "V" main volume flow at temperatures ≤ 70 °C.
CAUTIONdamage due to improper connection! Bear in mind that the device may be subject to additional stresses through the
connection of piping or hose connections to the facility system. Ensure that all connections to the facility system are free from
stresses. If necessary, provide support structures for the pipes.
CAUTIONProperty damage caused by leaks! Leaks in the connection pipes to the device can cause material damage to the facility
system. Use only connection pipes with adequate resistance against the facility system temperature.
The device is pre-wired and must be adapted to match the local facility system conditions.
Proceed as follows:
1. Complete the water side connections from the device to the facility system.
2. Complete the electric connection as shown in the terminal plan, see chapter 6.5 "Electrical connection" on page 17 .
Note!
When connecting, ensure the valves and supply element options of the connecting pipes can be operated.
6.3.1 Fitting the add-on components
Note!
In this respect,
see the illustrations on the attached supplementary sheet.
Install the ball valves at the device.
