Ricoh Aficio SP 5200DN

1. Open the front cover by pushing the front cover release button.
1
2
2
CEC025
2. Pull the print cartridge out of the printer by holding the grips of the cartridge.
CEC026
3. Be sure to put the print cartridge on a stable, flat surface.
4. Wipe around the metallic registration roller by turning with a soft damp cloth.
CEC040
5. Take the new print cartridge from the box.
7. Maintaining the Printer
152
7
