Installing the Interface Units
Installing the Gigabit Ethernet Board
• The
printer's Ethernet and USB ports are not available when the Gigabit Ethernet board is installed in
to the printer. Use the Ethernet and USB ports on the Gigabit Ethernet board.
• Before beginning work, ground yourself by touching something metal to discharge any static
electricity. Static electricity can damage the Gigabit Ethernet board.
• Do not subject the Gigabit Ethernet board to physical shocks.
1. Check the contents of the package.
1. Gigabit Ethernet Board
2.
Protective caps (one each for the Ethernet port and the USB port)
3. Ferrite core
Design of the ferrite core varies according to printer model.
2. Turn off the power, and then unplug the power cord.
Installing the Interface Units
59
