Installing the Memory Expansion Units
The following procedure applies to Type 1 model only.
• Do not touch the inside of the controller board compartment. Doing so may cause a machine
malfunction or a burn.
Installing the Hard Disk
• Before
touching the hard disk, touch something metal to discharge any static electricity. Static electricity
can damage the hard disk.
• Do not subject the hard disk to physical shocks.
1. Check the package contains the following:
1. Hard disk
2.
Screws
2. Turn off the power to the printer, and then unplug the power cable and interface cable.
3. Remove the two screws holding the controller board in place.
