10. Click [Port], and then click [Add].
11. Click [Standard TCP/IP Port], and then click [OK].
See Windows Help if [Standard TCP/IP Port] does not appear.
12. Click [Next].
13. Enter the printer name or IP address in the [Printer Name or IP Address] box.
The [Port Name] text box automatically obtains a port name. Change this name if necessary.
When the device type selection appears, select "RICOH Network Printer C model".
14. Click [Next].
15. Click [Finish].
16. Check that the port of the selected printer is displayed in [Port].
17. Configure the user code, default printer, and shared printer as necessary.
18. Click [Continue].
19. Click [Finish].
20. Click [Finish].
When you are prompted to restart your computer, restart it by following the instructions that appear.
• To stop installation of the selected driver, click [Cancel] before installation is complete.
•
A message appears if there is a newer version of the printer driver already installed. If there is, you
cannot install the printer driver using Auto Run. If you still want to install the printer driver, use [Add
Printer]. See p.51 "Messages Displayed When Installing the Printer Driver".
Installing the PostScript 3 printer driver
1. Close all applications except this manual.
2. Insert the CD-ROM into the CD-ROM drive.
The installer starts.
Auto
Run may not work with certain operating system settings. If this happens, launch "Setup.exe" on
the CD-ROM root directory.
3. Select an interface language, and then click [OK].
The default interface language is English.
The printer driver with the selected language will be installed. The English printer driver is installed
when the following language is selected: Suomi, Magyar, Cestina, Polski, Portugues, Russian.
4. Click [PostScript 3 Printer Driver].
Under Windows Vista/7, and Windows Server 2008, proceed to step 6.
5. Click [Next].
Installing the Printer Driver for the Selected Port
13
