Tunnel end point setting
msh> ipsec ike {1|2|3|4|default} tunneladdr beginning IP address ending IP
address
• Enter the separate setting number [1-4] or [default] and specify the tunnel end point beginning
and ending IP address.
• Not specifying either the beginning or ending address displays the current setting.
IKE partner authentication method setting
msh> ipsec ike {1|2|3|4|default} auth {psk|rsasig}
• Enter the separate setting number [1-4] or [default] and specify the authentication method.
• Specify [psk] to use a shared key as the authentication method. Specify [rsasig] to use a certificate
at the authentication method.
• You must also specify the PSK character string when you select [psk].
• Note that if you select "Certificate", the certificate for IPsec must be installed and specified before
it can be used. To install and specify the certificate use Web Image Monitor.
PSK character string setting
msh> ipsec ike {1|2|3|4|default} psk PSK character string
• If you select PSK as the authentication method, enter the separate setting number [1-4] or
[default] and specify the PSK character string.
• Specify the character string in ASCII characters. There can be no abbreviations.
ISAKMP SA (phase 1) hash algorithm setting
msh> ipsec ike {1|2|3|4|default} ph1 hash {md5|sha1}
• Enter the separate setting number [1-4] or [default] and specify the ISAKMP SA (phase 1) hash
algorithm.
• To use MD5, enter [md5]. To use SHA1, enter [sha1].
• Not specifying the hash algorithm displays the current setting.
ISAKMP SA (phase 1) encryption algorithm setting
msh> ipsec ike {1|2|3|4|default} ph1 encrypt {des|3des}
• Enter the separate setting number [1-4] or [default] and specify the ISAKMP SA (phase 1)
encryption algorithm.
• To use DES, enter [des]. To use 3DES, enter [3des].
• Not specifying an encryption algorithm displays the current setting.
ISAKMP SA (phase 1) Diffie-Hellman group setting
msh> ipsec ike {1|2|3|4|default} ph1 dhgroup {1|2|14}
• Enter the separate setting number [1-4] or [default] and specify the ISAKMP SA (phase 1) Diffie-
Hellman group number.
7. Enhanced Network Security
124
