Ricoh Aficio SP 5200DN

3. Remove the two screws and remove the cover of the slot in which the 1284 interface board
is installed.
CEC061
4. Fully insert the IEEE 1284 interface board.
CEC066
5. Tighten the two screws to secure the interface board.
Check the IEEE 1284 interface board is connected firmly to the interface board slot.
CEC060
• Confirm
that the IEEE 1284 interface board was correctly installed by printing the configuration page.
If it is correctly installed, "Parallel Interface" will appear for "Device Connection" on the configuration
page.
3. Installing Options
64
3
