Insert the SD card in the appropriate slot as follows:
•
Upper slot: SD font card, NetWare card, IPDS card
• Lower slot: VM card, ELP-NX card
The SD card supplied with the optional hard disk (Type 1 model only) can be used in either of the
two slots.
To export the printer settings by selecting [Machine Settings Export], insert the SD card on which the
settings are to be stored into the lower slot.
If you want to use two or more SD cards that can be inserted in the same slot, contact your sales and
service representative.
5. Reattach the cover over the SD card. Fasten the one screw to secure the cover.
If the ELP-NX card is inserted in the printer, the installation will automatically start when the printer is
turned on. After the installation is complete, restart the printer.
• Do not touch the card while the printer is in use. It may come loose, even if pushed only slightly. The
slot cover must be reattached.
Installing the SD Memory Card Options
67
