Ricoh D096 - 4.7.8 REGISTRATION CLUTCH; 4.7.9 REGISTRATION SENSOR

Paper Feed Section
D096 4-40 SM
4.7.8 REGISTRATION CLUTCH
1. Rear cover
2. High-voltage power supply board (with the bracket) [A] (
x 4, all connectors)
3. Registration clutch [B] (
x 1, x 1)
4.7.9 REGISTRATION SENSOR
1. Open the right door.
2. Registration sensor [A] (
x 1)
