Ricoh D096 - 5.2.10 PAPER JAM COUNTERS (SP 7504)

Using SP Modes
SM 5-21 D096
Service
Tables
Test Patterns Using IPU
46 Trimming Area (A3)
47 A4 Gradation Patches 1 (128 Grades)
48 A4 Gradation Patches 2 (128 Grades)
49 Trimming Area (A4)
Test Patterns Using SBU
No. Pattern
51 Grid Pattern (double dot)
52 Gray scale 1 (256 grades)
53 Gray scale 2 (256 grades)
5.2.10 PAPER JAM COUNTERS (SP 7504)
The table lists the menu numbers (the last three digits of SP 7504 XXX) and the paper jam
timings and locations.
Code
001 Paper jam occurs at power on.
010 Paper does not reach the registration sensor (from a paper tray).
050 Paper does not reach the registration sensor (from the by-pass tray).
070 Paper is caught at the registration sensor.
120 Paper is caught at the exit sensor (previous page).
121 Paper does not reach the exit sensor.
122 Paper is caught at the exit sensor.
