6.3 BLOWN FUSE CONDITIONS
All the fuses in the following table are on the power supply board.
Fuse
Rating
120 V 220 – 240 V
FU1 15A/125V 8A/250V
FU2 5A/125V 2.5A/250V
FU3 1A/250V 1A/250V
FU4 4A/250V 4A/250V
FU5 4A/250V 4A/250V
FU6 4A/250V 4A/250V
FU7 4A/250V 4A/250V
