Ricoh D096 - 5.2.5 OUTPUT CHECK (SP 5804)

Using SP Modes
D096 5-12 SM
5.2.5 OUTPUT CHECK (SP 5804)
- Conducting an Output Check –
 To prevent mechanical or electrical damage, do not keep an electrical component
on for a long time.
1. Select SP 5804.
2. Select the number (see the table below) corresponding to the component.
3. Select "ON."
4. To stop the operation, select "OFF."
- Output Check Table -
Number 005, 006, 040, and 041 may not respond when the fusing temperature is high.
Num. Component
001 Main Motor Forward
002 Main Motor Reverse
003 Quenching Lamp
004 Toner Supply Motor Forward
005 Fan Motor High
006 Fan Motor Low
007 Registration Clutch
008 By-pass Feed Clutch
009 Upper Feed Clutch
010 Lower Feed Clutch
011 BK-Low Lift Motor Up
012 BK-Low Lift Motor Down
013 Relay Clutch
