Ricoh D096 - 6.2 ELECTRICAL COMPONENT DEFECTS; 6.2.1 SENSORS

Electrical Component Defects
D096 6-2 SM
6.2 ELECTRICAL COMPONENT DEFECTS
6.2.1 SENSORS
Component CN Condition Symptom
Registration
111-2
(BICU)
Open
The Paper Jam message will appear
whenever a copy is made (paper has not
reached the sensor).
Shorted
The Paper Jam message appears even if
there is no paper at the sensor.
Paper End
114-2
(BICU)
Open
The Paper End indicator lights when the
1st paper tray is selected, even if there is
paper in the tray.
Shorted
The Paper End indicator does not light
when the 1st paper tray is selected, even
if there is no paper in the tray. The Paper
Jam message will appear whenever a
copy is made from the 1st paper tray.
By-pass Paper End
136-7
(BICU)
Open
The Paper End indicator lights when the
bypass tray is selected, even if there is
paper in the tray.
Shorted
The Paper End indicator does not light
when the bypass tray is selected, even if
there is no paper in the tray. The Paper
Jam message will appear whenever a
copy is made from the bypass tray.
Exit
124-2
(BICU)
Open
The Paper Jam message will appear
whenever a copy is made (paper has not
reached the sensor).
Shorted The Paper Jam message appears even if
