Ricoh D096 - 5.2.3 MEMORY CLEAR

Using SP Modes
SM 5-5 D096
Service
Tables
5.2.3 MEMORY CLEAR
This machine stores all the data in the NVRAM on the BICU. The data is cleared by SP
5801 2 (see exceptions)
002 Main Motor Reverse
003 Quenching Lamp
Data NVRAM Cleared by Remarks
All data BICU SP 5801 2
- Exceptions -
SP 5801 2 clears most of the settings and counters stored in the NVRAM on the BICU (the
values return to their default values). However, the following settings are not cleared:
 SP 5807 (Area Selection)
 SP 5811 1 (Serial Num Input [Code Set])
 SP 5811 3 (Serial Num Input [ID2 Code Display])
 SP 5812 1 (Service TEL [Telephone])
 SP 5812 2 (Service TEL [Facsimile])
 SP 5907 (Plug & Play: Not used in this model)
 SP 7 (Data Log)
 SP 8 (History)
Use SP 5802 2 (basic machine) after you have replaced the BICU NVRAM or when the
BICU NVRAM data is corrupted. When the program ends normally, the message
"Completed" shows.
- With Flash Memory Card
1. Upload the NVRAM data to a flash memory card (
NVRAM Data Upload/Download
(SP 5824/5825)).
2. Print out all SMC data lists (
SMC Print (SP 5990)).
 Be sure to print out all the lists. You have to manually change the SP settings
if the NVRAM data upload ends abnormally.
3. Select SP 5801 2.
4. Press the OK key.
