SP Mode Tables
SM Appendix 4-1 D096
Appendix:
SP Mode
Tables
4. APPENDIX: SP MODE TABLES
4.1 SP MODE TABLES
The following codes are used:
Asterisk (*): The settings are saved in the NVRAM. Most of them return to the default
values when you execute SP 5801 2
The DFU menu is for design or factory use only. You must not change the settings.
Brackets ([ ]): The brackets enclose the setting rage, default value, and minimum step
(with unit) as follows: [Minimum to Maximum / Default / Step].
4.1.1 SP1-XXX (FEED)
1001*
Leading Edge Registration
Adjusts the printing leading-edge registration from paper trays.
1001 1 All Trays
[–9.0 to 9.0 / 0.0 / 0.1 mm/step] (
Copy
Adjustments Printing/Scanning)
1001 2 By-pass
1002*
Side-to-Side Registration
Adjusts the printing side-to-side registration from each paper feed station,
using the Trimming Area Pattern (SP 5902, No.10). Adjustments are
supported for all 4 possible feed trays (including optional trays).
The SP 1002 1 setting is applied to all trays, not just the 1st tray. Settings for
trays 2 to 4 are offsets relative to the SP 1002 1 setting.
For duplex copies, the value for the front side is determined by SP 1002 1 to
4, and the value for the rear side is determined by SP 1002 6.
1002 1 1st tray
[–9.0 to 9.0 / 0.0 / 0.1 mm/step] (
Copy
Adjustments Printing/Scanning)
1002 5 By-pass
