SP Mode Tables
D096 4-2 SM Appendix
1003*
Paper Feed Timing
Adjusts the amount of buckle the paper feed clutch applies to the paper after
the registration sensor is activated. A higher setting applies greater buckling.
1003 1 1st tray
[0 to 10 / 5 / 1 mm/step]
1003 4 By-pass feed
[0 to 10 / 6 / 1 mm/step]
1007
Display By-pass
1007 1 Display By-pass Displays the by-pass paper width switch output.
1103*
Fusing Idling
This program decides the action of the Fusing Drive Release Mechanism.
When you select "1," the contact/release control is disabled and the drive
power is always transmitted to the fusing unit. As a result, the machine takes
a longer time to warm up the fusing unit. Use SP 1103 1 if fusing quality is low
even when the room temperature is not very low.
1103 1 Fusing Idling
[0 = No / 1 = Yes]
1105*
Fusing Temperature Adjustment
Adjusts the target fusing temperature. "Center" indicates the center of the
roller; "End" indicates the front and rear ends.
1105 1 Warm Up-Center
[140 to 180 / 160 / 1°C/step]
1105 2 Warm Up-End
1105 3 Standby-Center
[140 to 170 / 155 / 1°C/step]
1105 4 Standby-End
[140 to 165 / 150 / 1°C/step]
1105 5 Copying-Center
[140 to 185 / 160 / 1°C/step]
1105 6 Copying-End
