Using SP Modes
D096 5-4 SM
5.2.2 ID SENSOR ERROR ANALYSIS (SP 2221)
The image quality may become very bad when the ID sensor does not operate properly.
However, there is no such SC code that indicates ID-sensor malfunction; instead, SP 2221
shows you some information on the ID sensor. Check this information when the image
quality is not very good.
The table lists the information shown with SP 2221 (ID Sensor Error Analysis).
SP Error condition Possible cause Remarks
SP 2221 1 Vsg
(VG in the display)
Vsg < 2.5V or
(Vsg – Vsp) <
1.00V
ID sensor defective
ID sensor dirty
Drum not charged
SP 2221 2 Vsp
(VP in the display)
Vsp > 2.5V or
(Vsg – Vsp) <
1.00V
Toner density very low
ID sensor pattern not
created
SP 2221 3 Power
(PW in the
display)
Vsg < 3.5V
when maximum
power (979) is
applied
ID sensor defective
ID sensor dirty
Drum not get charged
Power source for the
ID-sensor light
SP 2221 4 Vsdp No Error
Conditions
SP 2221 5 Vt Vt > 4.5V or
Vt < 0.2V
TD sensor defective
SP 2221 6 Vts
