Ricoh D096 - 4.1.3 SP4-XXX (SCANNER)

SP Mode Tables
SM Appendix 4-13 D096
Appendix:
SP Mode
Tables
4.1.3 SP4-XXX (SCANNER)
4008*
Sub-Scan Magnification (Scanner)
[-0.9 to +0.9 / 0.0 / 0.1%/step]
4008 1
Adjusts the actual sub-scan direction scanning magnification. The higher the
setting, the lower the scanner motor speed.
4009*
Main Scan Magnification (Scanner)
[–0.9 to +0.9 / 0.0 / 0.1%/step]
4009 1
Adjusts the magnification along the main scan direction, for scanning.
The specification is 100 ± 1.0%
Main scan magnification is implemented in steps of 0.5. Accordingly, your
input value should be a multiple of 0.5 (–1.0, –0.5, 0, +0.5, or +1.0)
4010*
Leading Edge Registration
(Scanner)
[–5.0 to +5.0 / 0.0 / 0.1 mm/step]
4010 1
Adjusts the leading edge registration for scanning in platen mode (
Copy
Adjustments Printing/Scanning).
(–): The image moves toward the leading edge.
(+): The image moves toward the trailing edge
The specification is 2 ± 1.5 mm.
4011*
Side-to-side Registration
(Scanner)
[–4.2 to +4.2 / 0.0 / 0.1 mm/step]
4011 1
Adjusts the side-to-side registration for scanning in platen mode (
Copy
Adjustments Printing/Scanning)
Increasing the value shifts the image to the right
The specification is 2 ± 1.5 mm.
