Using SP Modes
SM 5-15 D096
Service
Tables
5.2.7 NVRAM DATA UPLOAD/DOWNLOAD (SP 5824/5825)
Make sure that you turn off the main switch before inserting or removing a flash
memory card. Installing or removing a flash memory card while the main switch is
on may damage the BICU or memory.
- Overview -
You can copy the data from the NVRAM to a flash memory card (NVRAM Upload), or from
a flash memory card to the NVRAM (NVRAM download).
SP 5824 1
(NVRAM Upload)
From the BICU to a
flash memory card
SP 5825 1
(NVRAM Download)
From a flash memory
card to the BICU
You should execute NVRAM Upload before replacing the NVRAM or before executing SP
5801 2 (
Memory Clear). You can copy back the data from the flash card to the NVRAM
as necessary.
- NVRAM Upload (SP 5824 1) -
1. Turn off the main switch.
2. Remove the card cover [B] (1 rivet).
3. Turn the face of the flash memory card [A] ("A" is printed on it) toward your left-hand
