SP Mode Tables
SM Appendix 4-25 D096
Appendix:
SP Mode
Tables
4.1.5 SP6-XXX (PERIPHERALS)
6006*
ADF Adjustment (
ADF Image Adjustment)
NOTE: Available menus depend on the machine model and its configuration.
6006 1
ADF Adjustment (StoS/Front
Regist)
[–5.0 to +5.0 / 0.0 / 0.1 mm/step]
Adjusts the side-to-side registration for the front side of the original, for ADF
mode. Use the
key to select "+" or "–" before entering the value
6006 2
ADF Adjustment (Leading Regist)
[–5.0 to +5.0 / 0.0 / 0.1 mm/step]
Adjusts the leading edge registration for ADF mode. Use the key to select
"+" or "–" before entering the value.
6006 3
ADF Adjustment (Trailing Erase)
[–3.0 to +3.0 / –1.0 / 0.1 mm/step]
Adjusts the trailing edge erase margin for ADF mode. Use the key to
select "+" or "–" before entering the value.
6006 5
ADF Adjustment (Sub-scan
Magnif)
[–0.9 to +0.9 / 0.0 / 0.1 %/step]
Adjust the sub-scan magnification for the ADF.
6009
ADF Free Run
6009 1 Performs an ADF free run. Press "ON" to start; press "OFF" to stop.
6901
Display ADF/APS
6901 1
Displays the status of the ADF original size sensors ( ADF APS Sensor
Output Display (SP 6901)).
