Installation Requirements
SM 2-1 D096
Installation
2. INSTALLATION
2.1 INSTALLATION REQUIREMENTS
Before installing options, please do the following:
If there is a printer option in the machine, print out all data in the printer buffer.
Turn off the main switch and disconnect the power cord, the telephone line, and
the network cable.
2.1.1 ENVIRONMENT
–Temperature and Humidity Chart–
Temperature Range:
10°C to 32°C (50°F to 89.6°F)
Humidity Range: 15% to 80% RH
Ambient Illumination: Less than 1,500 lux (do not expose to direct sunlight)
Ventilation: 3 times/hr/person or more
Ambient Dust: Less than 0.075 mg/m
3
(2.0 x 10-6 oz/yd3)
