Ricoh D096 - 4.7.2 FRICTION PAD; 4.7.3 PAPER END SENSOR

Paper Feed Section
SM 4-35 D096
Replacement
and
Adjustment
4.7.2 FRICTION PAD
1. Paper cassette
2. Clip [A]
3. Push the shaft back through the opening, so that the roller moves clear of the friction
pad.
4. Friction pad [B]
4.7.3 PAPER END SENSOR
1. Paper cassette
2. Paper end sensor [A] (
x 1)
