Ricoh D096 - 1.3 OPTIONAL EQUIPMENT; 1.3.1 ADF

Optional Equipment
SM Appendix 1-13 D096
Appendix:
Specifications
1.3 OPTIONAL EQUIPMENT
1.3.1 ADF
Original Size:
Standard sizes (Single-sided mode only):
 A3 to A5, 11" x 17" to 5
1
/
2
" x 8
1
/
2
"
Non-standard sizes (Single-sided mode only):
 Max. width 297 mm
 Min. width 105 mm
 Max. length 1,260 mm
 Min. length 128 mm
Original Weight: 52 – 105 g/m
2
(14 – 28 lb)
Table Capacity: 30 sheets (80 g/m
2
, 22 lb)
Original Standard Position: Center
Separation: FRR
Original Transport: Roller transport
Original Feed Order: From the top original
Reproduction Range: 50 – 200%
Power Source: 24 and 5 Vdc (from the main frame)
Power Consumption: 25 W
Dimensions (W x D x H): 550 mm x 470 mm x 90 mm
Weight: Not above 7 kg (15 lb)
