SP Mode Tables
SM Appendix 4-5 D096
Appendix:
SP Mode
Tables
4.1.2 SP2-XXX (DRUM)
2001*
Charge Roller Bias Adjustment
2001 1
Printing
[–2100 to –1500 / –1700 / 1 V/step]
Adjusts the voltage applied to the charge roller when printing. The actually
applied voltage changes automatically as charge roller voltage correction is
carried out. The value you set here becomes the base value on which this
correction is carried out.
2001 2
ID sensor pattern
[0 to 400 / 300 / 1 V/step]
Adjusts the voltage applied to the charge roller when generating the Vsdp ID
sensor pattern (as part of charge roller voltage correction). The actual
charge-roller voltage is obtained by adding this value to the value of SP 2001
1.
2101*
Erase Margin Adjustment
2101 1
Leading edge
[0.0 to 9.0 / 2.0 / 0.1 mm/step] (
Copy Adjustments
Printing/Scanning)
Specification: 2 ± 1.5 mm
Adjusts the leading edge erase margin.
2101 2
Trailing
[0.0 to 9.0 / 3.0 / 0.1 mm/step] (
Copy Adjustments
Printing/Scanning)
Specification: 2 +2.5/–1.5 mm
Adjusts the trailing edge erase margin. The rear trailing edge is this value
plus 1.2 mm.
2101 3
Left side
[0.0 to 9.0 / 2.0 / 0.1 mm/step] (
Copy Adjustments
Printing/Scanning)
Specification: 2 ± 1.5 mm
Adjusts the left edge erase margin. The rear left edge is this value plus 0.3
mm.
