Using SP Modes
SM 5-17 D096
Service
Tables
5.2.8 FIRMWARE UPDATE PROCEDURE
This section shows how to update the firmware.
The machine has the following firmware programs
Firmware Type SP Mode
Engine (BICU) 7801 2
- Engine (BICU) Firmware Update Procedure -
1. Turn the main switch off.
2. Remove the card cover [B] (1 rivet).
3. Insert the flash memory card [A].
4. Press down the power switch on the operation panel and hold it, and turn on the main
switch.
5. Select "Execute" [C].
To Next Page
