Ricoh D096 - 5.2.4 INPUT CHECK (SP 5803)

Using SP Modes
SM 5-7 D096
Service
Tables
5.2.4 INPUT CHECK (SP 5803)
- Conducting an Input Check -
1. Select SP 5803.
2. Select the number (see the table below) corresponding to the component.
3. Select "Execute." The copy mode is activated.
4. The sign "01H" or "00H" show (see the table below).
- Input Check Table -
Num. Sensor/Switch 01H 00H
001 Safety SW Open Closed
002 Safety SW-LD 5V Open Closed
003 Right Cover SW Open Closed
004 Right Low Cover SW Open Closed
005 Tray Cover SW Open Closed
006 Upper Relay S Paper detected Not detected
007 Lower Relay S Paper detected Not detected
008 Vertical Trans S Paper detected Not detected
009 Registration Sensor Paper detected Not detected
010 Exit Sensor Paper detected Not detected
011 Duplex Inverter S Paper detected Not detected
012 Duplex Entrance S Paper detected Not detected
013 Duplex Exit S Paper detected Not detected
014 By-pass PE S Paper detected Not detected
015 By-pass P Size S *1
016 Upper PE S Paper detected Not detected
