Using SP Modes
D096 5-8 SM
Num. Sensor/Switch 01H 00H
017 Lower PE S Paper detected Not detected
018 Upper P Size SW *1
019 Lower P Size SW *1
020 BK-Upper Paper End S Paper detected Not detected
021 BK-Lower Paper End S Paper detected Not detected
022 BK-Up P Size SW *1
023 BK-Low P Size SW *1
024 BK-Up P Height S *2
025 BK-Low P Height S *2
026 BK-Upper Lift S At upper limit Not at upper limit
028 BK type *3
030 Duplex Installed Installed Not installed
031 Lower Lift S At upper limit Not at upper limit
032 Main M Lock Locked Not locked
033 Polygon M Lock Locked Not locked
034 BK-Lift M Lock Locked Not locked
035 Total CO Install Installed Not installed
036 Key CO Install Installed Not installed
037 L-Synchronization Detected Not detected
038 DF-Position S Detected Not detected
039 DF-Cover Open S Detected Not detected
040 DF-Original Set S Detected Not detected
