Ricoh D096 - Page 137

Using SP Modes
SM 5-9 D096
Service
Tables
Num. Sensor/Switch 01H 00H
041 DF-Registration S Detected Not detected
042 DF-Exit S Detected Not detected
043 DF-Trailing S Detected Not detected
044 DF-Reverse S Detected Not detected
045 Platen Cover S Open Closed
046 1 bin Installed Installed Not installed
047 1 bin Exit S Paper detected Not detected
048 1 bin Paper S Paper detected Not detected
049 1 bin Tray S Open Closed
050 Fan Motor Lock High speed Not high speed
051 2 Tray BK Install Installed Not installed
053 HP Sensor Detected Not detected
054 Duplex Fan M Lock Locked Not locked
 *1 Paper Size
Copier 00 01 02 03 04 05 06 07
Europe Not set A4 LEF
8Hx13
SEF
A4 SEF A5 LEF LT LEF -- A3 SEF
North
America
Not set A4 LEF
8Hx13
SEF
LT SEF
LG
SEF
LT LEF --
DLT
SEF
China Not set A4 LEF B5 LEF A4 SEF A5 LEF B4 SEF -- A3 SEF
