Ricoh D096 - 4.6 PCU SECTION; 4.6.1 PCU

PCU Section
D096 4-26 SM
4.6 PCU SECTION
4.6.1 PCU
1. Toner bottle with the holder [A]
2. Open the right door.
3. Press the latch [B] and pull out the PCU [C].
 Do not touch the OPC drum surface with bare hands.
4. Load new developer (
p.4-32).
5. Do SP 2214 to reinitialize the TD sensor when you reassemble.
