Ricoh D096 - 2.6 TRAY HEATER; 2.6.1 TRAY HEATER

Tray Heater
SM 2-15 D096
Installation
2.6 TRAY HEATER
 Unplug the machine power cord before starting the following procedure.
2.6.1 TRAY HEATER
1. Remove the 1st tray cassette [A].
2. Remove the rear cover.
3. Pass the connector [B] through the opening [C] and install the tray heater [D] (
x 1).
