Installation Requirements
SM 2-3 D096
Installation
2.1.3 MINIMUM SPACE REQUIREMENTS
Place the copier near the power source, providing clearance as shown:
A (front): 750 mm (30")
B (left): 150 mm (6")
C (rear): 50 mm (2")
D (right): 250 mm (10")
The recommended 750 mm front space is sufficient to allow the paper tray to be pulled out.
Additional front space is required to allow operators to stand at the front of the machine.
2.1.4 POWER REQUIREMENTS
Make sure that the wall outlet is near the machine and easily accessible. After.
completing installation, make sure the plug fits firmly into the outlet.
Avoid multi-wiring.
Be sure to ground the machine
Input voltage:
North and South America, Taiwan: 110 – 120 V, 60 Hz, 12 A
Europe, Asia: 220 – 240 V, 50/60 Hz, 7 A
