SP Mode Tables
SM Appendix 4-17 D096
Appendix:
SP Mode
Tables
4901 11
Auto Adjustment Setting
[222 to 281 / 256 / 1/step]
Displays the parameter of the white-level adjustment. The value is based on
the result of SP 4901 12.
4901 12
Auto Adjustment-Result
[0 to 600 / 0 / 1/step]
Displays the result of the white-level adjustment. Normally, the value is
between 228 and 281 (including the both values). When the value is normal,
it is stored as the value of SP 4901 11.
4902*
Exposure Lamp ON
4902 1
Turns the exposure lamp on or off. To turn off the exposure lamp, select
"OFF". (The exposure lamp shuts off automatically after 180 seconds.)
4903*
ADS Level
[0 to 255 / 252 / 1/step]
4903 1 Adjusts the ADS level.
4904*
ADS Lower Limit
[0 to 255 / 80 / 1/step]
4904 1 Adjusts the ADS lower limit.
4905*
ADS Area Select
[0 = All / 1 = One]
4905 1
Checks the whole area (0 = All) or the area between 15 mm and 90 mm from
the left edge (1 = One) to adjust the ADS level.
