SP Mode Tables
D096 4-28 SM Appendix
7504 50
Counter-Each P Jam (Off-Regist By-pass)
Paper does not reach the registration sensor (from the by-pass tray).
7504 70
Counter-Each P Jam (On-Regist SN)
Paper is caught at the registration sensor.
7504 120
Counter-Each P Jam (On-Exit SN)
Paper is caught at the exit sensor (previous page).
7504 121
Counter-Each P Jam (Off-Exit SN)
Paper does not reach the exit sensor.
7504 122
Counter-Each P Jam (On-Exit SN)
Paper is caught at the exit sensor.
7505*
Counter-Each O Jam
[0 to 9999 / 0 / 1/step]
Displays the total number of the original jams on the ADF that have
occurred at a certain timing or at a certain location.
7505 210
Counter-Each O Jam (Off-Regist SN)
The original does not reach the registration sensor.
7505 211
Counter-Each O Jam (On-Regist SN)
The original is caught at the registration sensor.
7505 216
Counter-Each O Jam (Insufficient gap)
The distance between originals is not sufficient. This jam can occur when
the original is not of the standard size.
