TIP

When the voltage o

f signal source B is 0 V, the division result is treated as 0.

Figure 9.3 Arithmetic Operation Menu

Operation Result Display Window

Click or tap the Operation on/off swit

ch to enable the display of the arithmetic

operation result window. The source and the vertical scale parameters are displayed

at the top of the window, as shown in the figure below.

Figure 9.4 Operation Result Display Window

Math Operation

DHO1000 User Guide

118
